Specifications
Amplifier Program Power: 1200 W RMS / 2400 W Peak – Class D, Bi-Amplified with FIR DSP
Input Sensitivity: 8 dBu – 1.94 V
Input Impedance: 20 kΩ Balanced
Mains: 90–265 V, 50/60 Hz (Auto-sensing SMPS)
Average Current Draw: 3.7 A (Heavy duty musical program)
SPL (1 m): 141 dB continuous, 144 dB peak
Built-in DSP: 64-bit processing unit, factory presets + user-configurable
AD/DA Converters: 24-bit / 48 kHz / SNR >112 dB
Presets: Flat / Nearfield / Long Throw + 25 configurable user memories
Frequency Response (-10 dB): 50 Hz – 20 kHz
LF: 2 × 12″ neodymium woofers (3″ voice coil)
HF: 1 × 3″ neodymium compression driver
Waveguide: Symmetric dispersion
Directivity (HxV): 110° / 70° symmetric, 90° asymmetric
Dimensions (H × W × D): 976 × 354 × 506 mm
Weight: 39 kg
Finish: Premium birch plywood with high-resistance Polyurea® coating
Grille: Steel grille with dual-layer premium micro-foam finish
Rigging: Integrated quick-lock hardware
Connectors:
- 2 × XLR input / 2 × XLR link
- 1 × PowerCon™ input / 1 × PowerCon™ link
