AUX ARX118S

( 0 )

United States dollar ($) - USD

United States dollar ($) - USD

Compact, powerful, and adaptable — the ARX118S is the workhorse subwoofer for the Arcade X range. Its 18″ driver delivers solid, punchy bass that’s equally at home in live music venues, houses of worship, or mobile DJ rigs. Add in FIR DSP control and you’ve got low-end performance you can trust anywhere.

Single 18″ driver for punchy, reliable low-end
Optimised for portable and fixed installations
FIR DSP with factory and user presets
Durable birch plywood build with professional connectors

Specifications

Amplifier Program Power: 2400W Peak / 1200W RMS– Class D, D16 Active module with FIR filters
Input Sensitivity: +8 dBu – 1.94 V
Input Impedance: 8 Ω Balanced
Mains: 100–140 V or 180–265 V, 50/60 Hz (Auto-sensing SMPS)
Average Current Draw: 4.5 A (Heavy duty musical program)
SPL (1 m): 138 dB Peak
Built-in DSP: 64-bit processing unit, factory presets + user-configurable
AD/DA Converters: 24-bit / 48 kHz / SNR >108 dB
Presets: Multiple LF alignment modes + user memory slots
Frequency Range: 40 Hz – 500 Hz
Frequency Response (±3 dB): 50 Hz – 450 Hz
LF: 1 × 18″ woofer (280 mm magnet, 125 mm voice coil)
Cabinet Construction: 18 mm premium birch plywood
Dimensions (H × W × D): 570 × 765 × 705 mm
Weight: 51 kg
Finish: High-resistance black Polyurea® coating
Grille: Heavy-duty steel with premium acoustic cloth backing
Connectors:
• 2 × Neutrik® NL4MP input/link
• 1 × PowerCon™ input / 1 × PowerCon™ link
