AUX ARX115S

( 0 )

United States dollar ($) - USD

United States dollar ($) - USD

Low-end authority from a compact single 15″ driver – the ARX115S of Arcade X Family delivers deep, punchy bass that belies its size. Perfect for intimate venues, high-impact stage monitoring, or as a discreet bass extension for larger systems, it proves you don’t need towering cabinets to create a powerful, full-bodied sound.

Single 15″ driver for tight, focused bass
Ideal for smaller venues or supplementary low-end
FIR DSP with flexible tuning options
Lightweight, rugged design for easy transport

Specifications

Amplifier Program Power: 2000 W Peak / 1000 W RMS – Class D, D10 active module with FIR Filters
Input Sensitivity: +8 dBu – 1.94 V
Input Impedance: 8 Ω Balanced
Mains: 100–140 V or 180–265 V, 50/60 Hz (Auto-sensing SMPS)
Average Current Draw: 3.0 A (Heavy duty musical program)
SPL (1 m): 116 dB Peak
Built-in DSP: 64-bit processing unit, factory presets + user-configurable
AD/DA Converters: 24-bit / 48 kHz / SNR >108 dB
Presets: Multiple LF alignment modes + user memory slots
Frequency Range: 45 Hz – 400 Hz
Frequency Response (±3 dB): 50 Hz – 180 Hz
LF: 1 × 15″ woofer (220 mm magnet, 100 mm voice coil)
Cabinet Construction: 15 mm premium birch plywood
Dimensions (H × W × D): 540 × 440 × 540 mm
Weight: 29.5 kg
Finish: High-resistance black Polyurea® coating
Grille: Heavy-duty steel with premium acoustic cloth backing
Connectors:
• 2 × Neutrik® NL4MP input/link
• 1 × PowerCon™ input / 1 × PowerCon™ link
